Hot Coding Foil FC1
| Thickness of coding foil | 23.5±1.5 μm |
|---|---|
| Printing temperature | 95-160℃ |
| Ink thickness um | 11.5±1.5 μm |
| Printer Speed | 0-450 Times/Min |
| Compatible Printers | DY-8, HP-241, HP-30, ect |
| Working Medium | Polyester, PP, PE, PVC, PET, Aluminum |
| Available Color | black, red and blue |
Technical Parameters
Coding tape thickness：22.5±1.5 μm |
Printing temperature：100-140℃ |
Ink thickness：10.5±1.5 μm |
Product Features:
It has the advantages of strong adhesion, excellent abrasion resistance, easy to use, clear writing, not easy to fall off, high resolution, etc. Two-layer coating. Suitable for low-temperature freezing and low-speed labeling machines.
Scope of application:
It is widely used in pharmaceutical, food, packaging and other industries to print production date, batch number and necessary text labels on the soft outer packaging of products.
Applicable media:
Polypropylene film (PP), polyester film (PET), polyethylene film (PE), polyvinyl chloride film (PVC) and other materials
Hot Coding Foil FC2
| Thickness of coding foil | 22.5±1.5 μm |
|---|---|
| Printing temperature | 85-140℃ |
| Ink thickness um | 10.5±1.5 μm |
| Printer Speed | 0-300 Times/Min |
| Compatible Printers | DY-8, HP-241, HP-30, ect |
| Working Medium | Polyester, PP, PE, PVC |
| Available Color | black, red and blue |
Technical Parameters
Coding tape thickness：22.5±1.5 μm |
Printing temperature：100-140℃ |
Ink thickness：10.5±1.5 μm |
Product Features:
It has the advantages of strong adhesion, excellent abrasion resistance, easy to use, clear writing, not easy to fall off, high resolution, etc. Two-layer coating. Suitable for low-temperature freezing and low-speed labeling machines.
Scope of application:
It is widely used in pharmaceutical, food, packaging and other industries to print production date, batch number and necessary text labels on the soft outer packaging of products.
Applicable media:
Polypropylene film (PP), polyester film (PET), polyethylene film (PE), polyvinyl chloride film (PVC) and other materials
Hot Coding Foil FC3
| Thickness of coding foil | 23.5±1.5 μm |
|---|---|
| Printing temperature | 110-160℃ |
| Ink thickness um | 11.5±1.5 μm |
| Printer Speed | 0-300 Times/Min |
| Compatible Printers | DY-8, HP-241, HP-30, ect |
| Working Medium | Polyester, PP, PE, PVC |
| Available Color | black, red and blue |
Technical Parameters
Coding tape thickness：23.5±1.5 μm |
Printing temperature：100-140℃ |
Ink thickness：10.5±1.5 μm |
Product Features:
It has the advantages of strong adhesion, excellent abrasion resistance, easy to use, clear writing, not easy to fall off, high resolution, etc. Two-layer coating. Suitable for low-temperature freezing and low-speed labeling machines.
Scope of application:
It is widely used in pharmaceutical, food, packaging and other industries to print production date, batch number and necessary text labels on the soft outer packaging of products.
Applicable media:
Polypropylene film (PP), polyester film (PET), polyethylene film (PE), polyvinyl chloride film (PVC) and other materials
Hot Coding Foil SCF-900
| Thickness of coding foil | 23.5±1.5 μm |
|---|---|
| Printing temperature | 95-160℃ |
| Ink thickness um | 11.5±1.5 μm |
| Printer Speed | 0-600 Times/Min |
| Compatible Printers | DY-8, HP-241, HP-30, ect |
| Working Medium | Polyester, PP, PE, PVC |
| Available Color | black, white, yellow, gold, silver |
Technical Parameters
Coding tape thickness：23.5±1.5 μm |
Printing temperature：100-140℃ |
Ink thickness：10.5±1.5 μm |
Product Features:
It has the advantages of strong adhesion, excellent abrasion resistance, easy to use, clear writing, not easy to fall off, high resolution, etc. Two-layer coating. Suitable for low-temperature freezing and low-speed labeling machines.
Scope of application:
It is widely used in pharmaceutical, food, packaging and other industries to print production date, batch number and necessary text labels on the soft outer packaging of products.
Applicable media:
Polypropylene film (PP), polyester film (PET), polyethylene film (PE), polyvinyl chloride film (PVC) and other materials
